SKYZONE M5 FPV Monitor
SKYZONE M5 FPV Monitor: High-Performance 5-Inch Screen with 60FPS DVR Capability
The SKYZONE M5 FPV Monitor offers an impressive 5-inch display that delivers stunning visuals with a smooth 60FPS DVR capability. Designed for both hobbyists and professionals, this monitor ensures a crystal-clear view of your flights, enhancing your overall FPV experience. With its lightweight design and user-friendly interface, the M5 is perfect for on-the-go pilots looking for reliability and performance in one compact package. Elevate your flying experience with the SKYZONE M5!
SKYZONE M5 Monitor Features
- 5.8G 48CH Steadyview Receiver
- 5-inch LCD 800X480 highlight screen
- FOV up to 50°
- Bulit-in with heat-sink fan
- Channel scanning
- Type C connector to upgarde the firmware or power goggle
- Support Chinese and English
- Shuttle Wheel Control
- 2S-6S wide voltage support
- MJPEG 60FPS DVR, SD Max 128GB
Built-in Steadyview Receiver
Diversity mode: The receiver will compare with 2 RSSI, select the strongest output signal If the signal changes rapidly, the image will be tearing and rolling.
MIX Mode: Two signals are processed by complex circuits and algorithms, fuse the two signal into one, caused the more stable and clear image.
Multiple power supply
Take your FPV experience to new heights with the SKYZONE M5 monitor and its versatile power options! Use a 2-6S LiPo via the XT60 power cable, USB-C power supply, or 18650 Lion battery to keep the action going.
SKYZONE M5 FPV Monitor Specifications
Screen | 900 Lum High brightness LCD |
Resolution | 800*480 |
Receiver | 5.8Ghz 48 CH SteadyView Fusion Receiver |
Latency | ≤20ms |
Language | Chinese/English |
Power | DC6.5-25.2V USB 5V 18650 Li-ion |
Power Consumption | 12V / 520mA 6.24W |
DVR | MJEPG 60FPS, SD Card (Max 128GB) |
Battery Endurance | 1.5 Hour (18650 - 3000mAh) |
Antenna connector | SMA |
Dimension | 135*88*16mm |
Weight | 165±2g |
Package SKYZONE M5 FPV Monitor Included:
- 1* Monitor SKYZONE M5
- 2* 5.8GHz 2dB antenna
- 1* Video/Audio Cable
- 1* USB-C Cable
- 1* XT60-DC5.5*2.1 Power Cable
- 1* User Manual
